Coatings and Coverings

Precision craftsmanship to meet your demands

Coatings and Coverings

Siegling Proposition coatings for top results every time.

Please click on the graphic for technical details.

The specifications listed are based on Forbo Siegling's experience. However, our specifications and data do NOT cover all possible belt drive conditions. It is the responsibility of the belt drive system designer to ensure Forbo Siegling's belts are appropriate for a given system and application. The provided data is representative of our in-house experience and does not necessarily match product performance in industrial use.

Forbo Siegling cannot assume any liability concerning the suitability and process ability of our products. We also cannot assume liability for process results, damages or consequential damages associated with the use of our products. Note, ultimate tensile strengths are listed for references purposes only. Ultimate tensile strength values listed above are a theoretical calculation based on average cord strength and may not represent actual tensile test results.

Siegling Proposition - Coatings and coverings


Coating type Colour Coating material Hardness [Shore A] Thickness [mm] d factor* Permissible operating temperature [°C] Resistance Application Properties
01 Linatrile orange Nitrile (NBR) 50 2.4 -5 25 110 Simple fats and oils Wood conveying, chemical & oil contact conveying High friction and wear resistance
02 Linatex red Natural Rubber 40 1.6 -12 20 70 Wet abrasion Paper and wood industries, paper transport High friction and wear resistance; high flexibility at low temperatures
03 Linafood white Natural Rubber 38 3-8 20 70 Wet abrasion Food and pharmaceutical industries, paper transport FDA approval for direct contact with food
04 PU foil 85 transparent Polyurethane 85 1-4 30 80 Simple fats and oils Conveying of abrasive parts Cut resistant, extreme abrasion resistant
05 PU foil 60 transparent Polyurethane 60 2 25 80 Simple fats and oils Conveying of abrasive parts, glass & paper industries Cut resistant, extreme abrasion resistant
06 PU foil LG transparent Polyurethane 60 2 30 80 Simple fats and oils Conveying of abrasive parts Cut resistant, extreme abrasion resistant
07 G/GSTR green Rubber 50 2.6 25 100 Simple fats and oils Conveying steel plates, wood, paper etc. Good grip, wear resistance
08 G/AR black Rubber 70 3.5 25 70 Simple fats and oils General conveying, inclined conveying Good grip
09 PVC white PVC 65 1.5 25 80 Acids, salts & bases Food and pharmaceutical industries FDA approval for direct contact with food
10 PVC blue PVC 40 1-3 20 80 Acids, salts & bases Food and pharmaceutical industries Good grip
11 FG white PVC 65 3 30 80 Acids, salts & bases Paper and wood industries, glass conveying FDA approval for direct contact with food
12 Pimple top white PVC 65 1.8 20 80 Acids, salts & bases Food and pharmaceutical industries Good grip
13 Saw profile white PVC 65 3 25 80 Acids, salts & bases Pharmaceutical industries, wood and steel transport Good grip in one direction
14 PVC/AR white PVC 50 3.5 25 80 Acids, salts & bases Paper industry, glass conveying Very good grip
15 SZ / Porol black Neoprene rubber 165 kg/m3 2-15 10 70 Simple fats and oils Transport of fragile objects Flexible, compressible
16 SO orange Silicone 250 kg/m3 10-15 10 70 No fats and oilss Transport of fragile objects Flexible, extremely compressible
17 PU yellow Polyurethane foam 55 2-10 20 70 Simple fats and oils Vacuum & paper applications Good wear resistance
18 Sylomer yellow Polyurethane foam 160 kg/m3 12 10 70 Simple fats and oils Glass industry, bottle transport, paper industry Very flexible, Compressible, Printing form possible
19 Sylomer blue Polyurethane foam 220 kg/m3 6-12 15 70 Simple fats and oils Glass industry, bottle transport, paper industry Very flexible, compressible, printing form possible
20 Sylomer green Polyurethane foam 300 kg/m3 6-12 15 70 Simple fats and oils

21 Sylomer brown Polyurethane foam 400 kg/m3 6-12 20 70 Simple fats and oils Transport of fragile objects Very flexible, compressible, printing form possible
22 Sylomer red Polyurethane foam 500 kg/m3 12 25 70 Simple fats and oils Transport of fragile objects Very flexible, compressible, printing form possible
23 Vulcocell VS40MH beige Polyurethane foam 400 kg/m3 2-10 20 80 Simple fats and oils Transport of fragile objects Flexible, compressible
24 Novo 12 HC grey Polyester fleece --- 1.2 40 120 Simple fats and oils General conveying, glass conveying Antistatic
25 Novo 25 NA light grey Polyester fleece --- 2.5 25 120 Simple fats and oils General conveying, glass conveying Low friction
26 Silicone white Silicone 30 1-5 50 100 Simple fats and oils Transportation of hot and sticky parts Good grip
27 Chrome leather grey Leather --- 3 25 60 Simple fats and oils Transportation of hot and sticky parts Good grip
28 Polyamid fabric green Polyamid --- 0.5 60 60 No fats and oils Glass and paper industries, cutting tables Low friction
29 EPDM black Rubber 70 2-10 25 70 No fats and oils Solar industry, steel transport Good grip
30 Correx beige Natural Rubber 40 4-10 20 70 Simple fats and oils Extruder, transport of plastic boxes Good grip, printing form possible
31 Elastomer green Rubber 60 1-2 25 70 No fats and oils Glass and paper industries Good grip, good abrasion resistance
32 Teflon grey PTFE --- 0.3 300 200 Simple fats and oils Food and pharmaceutical industries Low friction
33 Viton black Rubber 75 1-5 25 200 No fats and oils Solar industry, hot forming of sheet steel industry Good grip, temperature resistant


* Factor x Thickness = smallest diameter
